Seamless switch between two pairs of balanced Inputs
Passive volume control ensures transparent
attenuation of the audio signal.
Absolute must-have for producers and sound engineers, CR 44 is the passive controller that allows the management of two pairs of monitors, for professional and home studio reference listening.
A small, compact and complete audio control room, CR-44 features two pairs of outputs on balanced XLR connectors (monitor A, monitor B), one pair of inputs on balanced XLR connectors (Input A), and on balanced TRS connectors (Input B) or 3.5 mm stereo mini-jack.
Passive volume control ensures transparent attenuation of the audio signal. On-board controls enable input and output selection, volume, muting, 20 dB attenuation, MONO function, and, last but not least, the Side Listen function, which allows selective listening to the stereo mix in its most "lateral" spatial zones.
|Type||Passive controller for monitor|
|Frequency response||0dBu Input: ±1dB 10Hz-30kHz|
|Distortion||0dBu Input@1kHz: 0.0005%|
|Crosstalk||0dBu Input@1kHz: -115dB|
|Signal-noise ratio||A-weighted: -115dB|
|Dimensions||140 mm x 79.5 mm x 128 mm|
|Input||A: (L,R) –balanced XLRs B: (L, R) balanced TRSs or 3.5 mm Stereo mini-jacks|
|Output||MONITOR A (L, R) balanced XLRs MONITOR B (L,R) balanced XLRs|
|Controls||Input selectors (A,B), and monitors (A,B) Volume, DIM, MUTE, SIDE LISTEN, MONO|
