USB to Stereo Balanced output
Plug & Play
Works with iOS and Android, no Drivers needed
Plug & Play
Works with iOS and Android, no Drivers needed
Multimedia D.I. Box
MDI-2M is a powerful, easy-to-use device that combines the features of a high quality D/A converter (up to 192 kHz - 24 bit) and a D.I. box in a compact, rugged and lightweight unit.
It allows you to send a balanced, high quality audio signal that is free of noise from your mobile devices to a mixer, PA system or studio monitor.
The headphones output allows you to monitor the stereo or mono signal.
This a completely plug & play device, iOS and Android compatible.
With additional USB-C Power supply MDI-2M charges your device also during playback
Features
- Multimedia DI Box
- 2x XLR-M balanced outputs
- USB powered
- Selectable PAD
- Ground Lift switch
- Headphones Output
- 101 x 38 x 140 mm
- 610gr
Product Code: 1740000071
TECHNICAL SPECIFICATIONS
General
| Type | Multimedia D.I. Box |
| Enclosure | Metal Housing |
| Dimensions W x H x D | 101mm x 38mm x 140mm |
| Weight | 610g |
Input & Controls
| Input | 1x 3.5mm stereo jack Aux In on 1x RCA input 1x Digital audio signal on USB-C |
| Output | 2x XLR-M 1x 3.5mm stereo jack Headphones output |
| Sampling frequency | 4.1/48/88.2/96/192 kHz; 16/24 bit |
| Compatibility | Windows 10 or later, Mac OS |
| Supported Formats | WDM, MME, CoreAudio, Direct Sound, WASAPI and .WAV |
| THD | <0.009% |
| Dynamic Range | 102 dBu |
| Controls | 1x Ground/Lift 1x Mono 1x Output level 1x Power ON LED 1x Headphone output level |
